Plus de références
Referencia
Peso neto (kg)
Couleur
Ø exterior (mm)
Ø interior (mm)
Longitud
Rayon de courbure
AIRCA 6
AIRCA 8
AIRCA 8C20
AIRCA 10
AIRCA 13
AIRCA 16
AIRCA 19
AIRCA 25
Dimensiones
Referencia
A (mm)
B (mm)
C (mm)
D (mm)
E (mm)
AIRCA 6
AIRCA 8
AIRCA 8C20
AIRCA 10
AIRCA 13
AIRCA 16
AIRCA 19
AIRCA 25
| Referencia | Peso neto (kg) | Couleur | Ø exterior (mm) | Ø interior (mm) | Longitud | Rayon de courbure | 3D |
|---|---|---|---|---|---|---|---|
| AIRCA 6 | 5.6 Kg | Negro | 13 mm | 6 mm | 40 m | 18.00 mm | |
| AIRCA 8 | 6.3 Kg | Negro | 15 mm | 8 mm | 40 m | 25.00 mm | |
| AIRCA 8C20 | 0.17 Kg | Negro | 15 mm | 8 mm | 20 m | 25.00 mm | |
| AIRCA 10 | 8.6 Kg | Negro | 18 mm | 10 mm | 40 m | 35.00 mm | |
| AIRCA 13 | 15.2 Kg | Negro | 22 mm | 13 mm | 40 m | 60.00 mm | |
| AIRCA 16 | 14.7 Kg | Negro | 25 mm | 16 mm | 40 m | 70.00 mm | |
| AIRCA 19 | 17.7 Kg | Negro | 28 mm | 19 mm | 40 m | 80.00 mm | |
| AIRCA 25 | 27.88 Kg | Negro | 34 mm | 25 mm | 40 m | 100.00 mm |
